UB AI 1013 BV
Characteristic Features And Uses UB AI 1013 BV is used as a topcoat with the base coat of THEIC Polyester or Polyesterimide to improve the Class of wire, heat shock, windability and refrigerant resistance The enamelled wires fully meet specification requirements of IS 13730-34/IEC 60317-34 for enamelled round copper wires, class 130L. UB AI 1013 […]
01. Overview
Product Description
Characteristic Features And Uses
- UB AI 1013 BV is used as a topcoat with the base coat of THEIC Polyester or Polyesterimide to improve the Class of wire, heat shock, windability and refrigerant resistance
- The enamelled wires fully meet specification requirements of IS 13730-34/IEC 60317-34 for enamelled round copper wires, class 130L.
- UB AI 1013 BV is generally recommended for use on wire diameters up to 2.0 mm dia. However, it can be used on thicker wires & rectangular wires by checking suitability on individual plant.
- Due to its excellent refrigerant resistance, it is ideally suitable for winding of hermetically sealed motors. UB AI 1013 BV/35 is UL approved under UL file No. E135382.
- It is made sure that any restricted substances listed in Restriction of Hazardous Substances (RoHS) Directive (2002/95/EC) is not used in the making of UB AI 1013 BV.
- UBAI 1013 BV/.. is generally used as a top coat over Polyesterimide based wire enamel, such as, UB TR 543-38 or ISOMID 860/35 LYC or UB SL 225-.. while manufacturing dual coated wires confirming to IS 13730 - 13 / IEC 60317 - 13 & IS 13730-29/IEC 60317-29 for Polyester (imide) over coated with Polyamide-imide enamelled round copper wires, class 200.
👀
